Incoloy 825

Incoloy 825

Inconel 825 Rods Manufacturers, Alloy 825 Sheet Exporters, Incoloy Alloy 825 / 825 Round Bars, Inconel 825 Bars Suppliers in India.


Mahendra Metals & Tubes Company is one of the pioneer exporting houses of Inconel 825 Round Bars , which was approved by the ASME Boiler and Pressure Vessel Committee. It was the first of these alloys and it was slightly modified into Incoloy 800H Bars, where this modification was to control carbon and grain size to optimize stress rupture properties.

Inconel 825 Flat Bars of Mahendra Metals & Tubes Company has further modifications to the combined titanium and aluminium levels to ensure optimum high temperature properties. The chemical balance allows the alloy to exhibit excellent resistance to carburization, oxidation and nitriding atmospheres.

Inconel 825 Hex Bars of Mahendra Metals & Tubes Company will not become embrittled even after long periods of usage in the 1200 Degree F - 1600 Degree F range where many stainless steels become brittle. Excellent cold forming characteristics typically associated with the nickel-chromium alloys are exhibited with Incoloy 800HT. When cold formed extensively the grain size produces a visibly undulated surface called "orange peel".

Inconel 825 Sheets of Mahendra Metals & Tubes Company offers higher elevated temperature characteristics and has better creeping and stress rupture properties at the temperature limits up to 1100 Degree F – 1800 Degree F or 593 Degree C to 982 Degree C. The chemical composition of Inconel 825 Plates is designed to provide exceptional resistance to various corrosive environments, where the majority of Incoloy alloys make additions to a nickel-iron-chromium base.


UNS N08825 Incoloy Alloy 825 Plates Distributor, Incoloy 825 Round Rods, WNR 2.4858 Incoloy 825 Steel Bars, Alloy 825 Strip Dealers in India.

Inconel Alloy 825 Specification

STANDARD Incoloy Alloy 825 / 825 / 825
WERKSTOFF NR. W.Nr 2.4858
UNS N08825
Bars ASTM B425
Sheets & Plates ASTM B424
Forging ASTM B564
Fittings ASTM B366 / B564
Pipe ASTM B423 (Seamless Pipe)
Applications Chemical Processing, Food processing, Industrial Heat Exchangers, Oil and gas well piping, Pulp and paper industry, Acid production, Nuclear Engineering etc.

Chemical Composition for Incoloy Alloy 825 UNS N08825

Fe Ni Cr S Ti Cu C Al Mn Si Mb
22.0 min 38.0-46.0 19.5-23.5 0.03 max .6-1.2 1.5-3.0 0.05 max 0.2 max 1.0 max 0.5 max 2.5-3.5

General Mechanical Properties UNS N08825 Alloy Inconel 825

Tensile (ksi) .2% Yield (ksi)
85 30-35
